Уборочная машина для яблок BERGLADY

для вишнисамоходная1 ряд

Multifunctional use beyond harvest
Our founder Michael never liked machines that are used only for a few weeks during harvest and remain idle for the rest of the year. The Berglady was developed as a further evolution of the Lady, designed to use the same base machine outside the harvest period. Thanks to its reinforced construction and predefined mounting points for optional attachments, the Berglady not only expands its harvesting capabilities but also enables various maintenance tasks to be performed throughout the year.

More power and stability
The Berglady features a stronger structure to safely carry heavier loads while maintaining full stability. It offers more powerful motors, optional reduction gearboxes and a 48V system and can handle loads of up to around 600 kg. A longer wheelbase and wider track provide a solid base, allowing two people to work on the pedestals during harvest with full fruit bins and enabling safe pruning on uneven or slippery ground. The system can operate on slopes up to around 40% and recovers braking energy on descents to extend battery life in hilly orchards.

Platform and pedestals when needed
Rather than a separate large machine, the Berglady is designed so a platform or harvesting pedestals can be mounted when required. The platform is mainly used for maintenance tasks such as pruning in winter, tying in spring, thinning during the growing phase or working on hail nets. Harvesting pedestals enable picking in mid and higher tree areas.

Reaching higher picking zones
The Berglady’s harvesting versatility is increased by attaching harvesting pedestals, allowing access to tree sections that would otherwise require ladders or a separate lifting platform. Depending on model and slope, heights between approximately 2.30 m and 3.50 m can be reached. Pedestals are adjustable to row widths that can vary between about 2.20 m and 3.50 m.

360° view - highlights

• Slope compensation off-loading bin
• Width-adjustable components
• Double wheels on both front and rear axles
• Different wheel options available
• Longer base frame for stability
• Small picking box placement
• Slight adjustability in angle and width
• Different standing heights available

Caractéristiques / spécifications techniques

• Engines: 2 DC motors, rated power 0.85 kW
• Gearboxes: Bevel spur gear
• Brakes: Electromagnetic
• Steering: Tank steering via joystick
• Control system: Forward and reverse travel via joystick
• Batteries: Lithium batteries, weight 7–20 kg (variants available)
• Charger: 5–30 A electronically regulated (standard)
• Driving speed: Stepless from 0 – max. 4 km/h
• Climbing ability: Max. 20% upwards without slope compensation; max. 40% with maximum slope levelling; max. 15% side slope
• Max. load capacity: For crate transport 400 kg; on platform max. 200 kg (including persons)
• Unladen weight: Approx. 250 kg + platform attachment 75/90 kg (depending on model)
• Tires: 16" × 6.50 × 8 tyres inside – tractor profile; optional outside tyres 16" × 6.50 × 8 (tractor) or 16" × 7.50 × 8 (garden profile)
• Total length: 1.55 / 1.70 m (depending on version)
• Total width: 0.90 / 1.40 m (depending on version)
• Working platform: Length 0.90 m; width 0.90 / 1.20 m (depending on version); unfolded 1.80 / 2.20 m; working height approx. 1.30 m
